Water Measurement

Metering Products

SpireTap & 280W-R

IoT Ultrasonic Water Metering

Your AMI Solution

Featuring a Stainless Steel Flow Body, SpireTap is designed to meet the demands of meter reading in all environments. Well established, with a wide install base, the 280W-R sets the industry standard for robust, reliable residential and commercial metering and remote data collection. Click Your Application below and tell us where you need to measure today!

  • AWWA C750, NSF61-G
  • 232 psi (PN16) at 203o F
  • OIML R49, ISO 4064 Class D
  • 10 year, replaceable battery
  • NB-IoT, LoRa, MBus and more AMI interfaace options
  • IP68/NEMA 6P
  • Threaded connection 5⁄8” x 3⁄4” to 1 1⁄2”
  • Flanged connection 1 1⁄2” and 2”

SpireTap for USA


280W-R for International

Contact us

img Your Application Datasheet US Datasheet INT’L 280W-R Manuals

Features & Benefits

  • For domestic water consumption metering
  • Cold water as well as water up to 60°C long term
  • No moving parts. Wear-free ultrasonic technology
  • Flow sensor made from NSF61-Annex G approved low lead brass
  • Patented sensor design
  • Robust, not impacted by water impurity. Meets the challenges of harsh environments
  • Excellent long-term stability. Accuracy does not degrade over time
  • No maintenance needed
  • No count on air
  • Leak detection
  • Not affected by magnetic interference
  • Low pressure drop
  • Free positioning for mounting
  • Battery life of 10 years
  • IP 68 water-proof
  • Humidity resistance. No water condensation risk on the display
  • Tamper-proof design
  • NIST calibration to AWWA C700 Standard
  • Smart and AMR/AMI ready with pulse, M-Bus, encoder or Wireless interface
  • Optional SpireCapture AMR/AMI and Billing solutions

Features & Benefits

  • For domestic water consumption metering
  • Cold water as well as water up to 60°C
  • No moving parts. Wear-free ultrasonic technology
  • Flow sensor made from brass
  • Patented sensor design
  • Robust, not impacted by water impurity. Meets the challenges of harsh environment, such as the Middle East and Africa
  • Excellent long-term stability. Accuracy does not degrade over time
  • No maintenance needed
  • Bi-directional flow
  • No count on air
  • Leakage detection
  • Not affected by magnetic interference
  • Low pressure drop
  • Free positioning for mounting
  • Battery for 10 more years
  • IP 68 water-proof
  • Humidity resistance. No water condensation risk on the display
  • Tamper-proof design
  • NIST calibration to OIML R49 Class 2 / Metrology ISO 4064 Class D
  • Smart and AMR ready with pulse, M-Bus, encoder or Wireless interface
  • Optional SpireCapture AMR/AMI and Billing solutions

Specifications US

rh20specs

Specifications INT'L

rh20specs
